What is auto connector HD098A-1.5-21?

Auto connector HD098A-1.5-21 is a type of automotive electrical connector that is commonly used in the automotive industry. These connectors play a vital role in the functioning of various electrical components in a vehicle, such as lights, sensors, and ignition systems.

We will take a closer look at the features, applications, and benefits of the HD098A-1.5-21 auto connector.

Features of Auto Connector HD098A-1.5-21:

1. Size and Shape:

The HD098A-1.5-21 connector is compact in size and has a rectangular shape. It is designed to fit perfectly in tight spaces in a vehicle's engine compartment, making it an ideal choice for modern automobiles.

2. Pin Configuration:

This auto connector has 21 pins, which are arranged in three rows, with seven pins in each row. The pins are made of high-quality materials, which provide excellent conductivity and durability.

3. Waterproof Design:

The HD098A-1.5-21 connector is designed to be waterproof. It has a rubber sealing around the pins, which prevents water and other contaminants from entering the connector. This feature makes it suitable for use in high-humidity environments, such as near the radiator or air conditioning system.

4. Multiple Uses:

One of the significant advantages of this auto connector is its versatility. It can be used in a variety of electrical components in a vehicle, including sensors, meters, relays, and switches. It is also compatible with different wire sizes, making it convenient for mechanics and technicians to use in various applications.

Applications of Auto Connector HD098A-1.5-21:

1. Lighting System:

The HD098A-1.5-21 connector is widely used in the lighting system of a vehicle. It connects the various lights, such as headlights, taillights, turn signals, and brake lights, to the electrical system. The use of this connector ensures a secure and stable connection, contributing to the proper functioning of the lights.

2. Engine Sensors:

Modern vehicles have a complex network of sensors that monitor various aspects of the engine, such as temperature, pressure, and air intake. The HD098A-1.5-21 connector is commonly used to connect these sensors to the engine control unit (ECU) or the engine management system (EMS).

3. Fuel Injection System:

The fuel injection system is an essential component of a vehicle's engine. It provides the right amount of fuel to the engine for combustion. The HD098A-1.5-21 connector is used to connect the fuel injectors to the electrical system, ensuring a smooth and efficient flow of fuel.

Benefits of Auto Connector HD098A-1.5-21:

1. Reliable and Durable:

One of the most significant advantages of the HD098A-1.5-21 connector is its reliability and durability. It is designed to withstand harsh conditions, such as extreme temperatures, vibrations, and moisture. These connectors are also known for their long lifespan, making them a cost-effective solution for automotive manufacturers.

2. Easy to Install:

Another benefit of this auto connector is its ease of installation. It comes with pre-installed wiring and pins, making it easy for mechanics and technicians to install without the need for additional tools or equipment. This feature also reduces the possibility of errors during installation, ensuring a secure and stable connection.

3. Cost-Effective:

The HD098A-1.5-21 auto connector is an economical choice for automotive manufacturers. Its compact size and versatile use make it suitable for a wide range of applications, reducing the need for multiple connectors. Its durability and long lifespan also make it a cost-effective option in the long run.

What is connector vs adaptor?

A database connector is a software that connects an application to any database. A database adapter is an implementation of a database connector. The connector is more at the conceptual level, while the adapter is at the implementation level, though they refer to the same thing.

What is a connector plug?

Male. The male part of a connector is called the plug, this generally includes the pin contacts for the connection. Female. The female part of the connector is called the socket, this generally holds the contact sockets where the male pins insert to create the connection.

YUEQING HAIDIE ELECTRIC was established in 2013. We provide a wide range of products for high-performance automotive electronics, from wiring to connectors, sensors, and wiring harness maintenance tools. The main products include automotive plug sockets,terminals,connectors,high temperature anti-corrosion silicone rubber jackets,computer board fittings,wire harness, etc.

FAQs Guide

1.What type of connector is Auto connectors?
2.About auto connector,do you have a price list?
3.About auto connector,How long to make a new mould?
4.About auto connector,I can’t find the product on your catalogue,only have par no. or picture
5.What is the working principle of Auto connectors?
6.How to deal with damaged Auto connectors?
7.Is there any temperature or environmental requirement for Auto connectors?
8.How does Auto connectors price compare to other traditional connectors?

1.What type of connector is Auto connectors?

We have a first -class management team, and we pay attention to teamwork to achieve common goals. Auto connectors are typically rectangular or circular connectors with multiple pins or sockets used to connect various electrical components in a vehicle.

They can come in different sizes and configurations depending on the specific application and manufacturer. Some common types of auto connectors include blade connectors, bullet connectors, and weatherpack connectors.

2.About auto connector,do you have a price list?

We only have few mainly products price list for your reference. For the others, please kindly send us your demand, then we would quote accordingly

3.About auto connector,How long to make a new mould?

30-45 days depending on the samples' complexity.

4.About auto connector,I can’t find the product on your catalogue,only have par no. or picture

Our catalogue shows most of our products, some new connectors, we didn't update, so please feel free to contact us with the part no. or picture.

5.What is the working principle of Auto connectors?

We should perform well in market competition, and the prices of auto connector products have a great competitive advantage. The working principle of auto connectors is based on the concept of electrical conductivity and mechanical connection.

These connectors are designed to establish a secure and reliable connection between two or more electrical components in a vehicle. The main components of an auto connector include male and female terminals, housing, and locking mechanism. The male terminal is a metal pin that carries the electrical current, while the female terminal is a socket that receives the male terminal. The housing is a plastic or metal casing that holds the terminals in place and provides protection from external elements.

When the male and female terminals are inserted into the housing, they make contact with each other, creating an electrical connection. The locking mechanism ensures that the terminals remain securely connected and prevents them from coming loose due to vibrations or other external forces. Auto connectors also have features such as sealing gaskets and waterproof coatings to protect the electrical connection from moisture and other contaminants.

In summary, the working principle of auto connectors involves the use of male and female terminals, housing, and locking mechanism to establish a secure and reliable electrical connection between components in a vehicle.

6.How to deal with damaged Auto connectors?

We maintain a certain amount of R&D investment every year and continuously improve operational efficiency to provide better services to our cooperative customers.

 1. Assess the damage: The first step in dealing with damaged auto connectors is to assess the extent of the damage. Look for any visible signs of damage such as broken or bent pins, corrosion, or melted plastic. This will help you determine the best course of action.

 2. Clean the connectors: If the damage is minor, you can try cleaning the connectors with a contact cleaner or rubbing alcohol. This will remove any dirt, grime, or corrosion that may be causing connectivity issues.

 3. Repair broken pins: If the pins are broken or bent, you can try to straighten them using a small pair of pliers. If the pins are too damaged to be repaired, you may need to replace the entire connector.

 4. Replace damaged connectors: If the damage is extensive, it may be best to replace the damaged connectors. You can purchase replacement connectors from an auto parts store or online. Make sure to get the correct type and size for your vehicle.

 5. Solder the connections: If the wires inside the connector are damaged, you may need to solder them back together. This requires some skill and the right tools, so if you are not comfortable doing it yourself, it is best to take your vehicle to a professional.

 6. Use heat shrink tubing: After repairing or replacing the connectors, use heat shrink tubing to cover the connections. This will provide insulation and protect the connections from moisture and dirt.

 7. Test the connections: Once you have repaired or replaced the connectors, test them to ensure they are working properly. If there are still issues, you may need to seek professional help to diagnose and fix the problem.

 8. Prevent future damage: To prevent future damage to your auto connectors, make sure to regularly inspect and clean them. Also, avoid using excessive force when connecting or disconnecting them.

7.Is there any temperature or environmental requirement for Auto connectors?

Our mission is to provide customers with the best solutions for auto connector. Yes, there are certain temperature and environmental requirements for auto connectors. These requirements vary depending on the specific type of connector and its intended use.

Some common requirements include:

  1. Temperature range: Auto connectors are designed to operate within a specific temperature range. This range can vary from -40°C to 125°C, depending on the type of connector. It is important to ensure that the connector is not exposed to temperatures outside of this range, as it can affect its performance and durability.

 2. Moisture and humidity: Auto connectors are often exposed to moisture and humidity, especially in outdoor or under-the-hood applications. Therefore, they are designed to be resistant to these environmental factors. Some connectors may have specific IP (Ingress Protection) ratings that indicate their level of protection against moisture and dust.

 3. Chemical resistance: Auto connectors may come into contact with various chemicals, such as engine oils, fuels, and cleaning agents. Therefore, they are designed to be resistant to these substances to prevent corrosion and damage.

 4. Vibration and shock resistance: Auto connectors are subjected to constant vibration and shock in a vehicle's engine compartment. They are designed to withstand these forces and maintain a secure connection.

 5. UV resistance: Connectors used in outdoor applications must be resistant to UV radiation to prevent damage and degradation. It is important to consider these temperature and environmental requirements when selecting an auto connector to ensure its proper functioning and longevity.

8.How does Auto connectors price compare to other traditional connectors?

We are a professional auto connector company dedicated to providing high quality products and services. Auto connectors typically have a higher price compared to traditional connectors due to their specialized design and features. Auto connectors are designed to withstand harsh environments, high temperatures, and vibrations, making them more durable and reliable for automotive applications.

They also have specific features such as waterproofing, corrosion resistance, and high current-carrying capacity, which add to their cost. On the other hand, traditional connectors are designed for general use and may not have the same level of durability and features as auto connectors. They are also produced in larger quantities, making them more cost-effective. Overall, the price of auto connectors may be higher, but it is justified by their specialized design and features that make them essential for automotive applications.
